Quatro Planetary Gearing for Sugar Cane

Sugar cane processing applications include; cane carriers and shredders, pressure feeders, diffusers, crystallisers and pulp presses.

• Cooking, washing and bleaching drives customised to our customers’ specifications
• Robust sealing technology
• Reliable operation
• High process availability
• Low maintenance costs
• Trouble-free installation
• High performance with low running costs

Cane Carrier Drives:

• Coaxial Quatro+ planetary gearbox
• Piggy back design
• Double site torque arm with torsion shaft support
• Hollow shaft output with shrink disk
• Typical 160:1 ratio
• Output torque up to 450,000 Nm

Cane Shredder Drives:

• Coaxial Quatro+ planetary gearbox
• Shaft mounted
• Double side liked torque arm
• Splined output shaft
• Motor support
• Belt drive
• Ratio up to 180:1
• Output torque up to 450,000 Nm

Pressure Drives:

• Coaxial Quatro+ planetary gearbox
• Shaft mounted
• Single side torque arm
• Hollow shaft with shrink disc
• Oil circulation system
• Ratio up to 300:1
• Output torque up to 800,000 Nm

Diffuser:

• 4 stage bevel helical Quatro+ planetary gearbox
• Double site torque arm with torsion shaft support or single site torque arm
• Hollow shaft output with shrink disc
• Ratio up to 4,500:1
• Output torque up to 3,000,000 Nm
• Split torque drives available for drop-in replacement

Crystalliser Gearboxes :

• Four stage coaxial or bevel helical Quatro+ planetary gear unit
• Vertical mounting position
• Shaft mounted
• Hollow shaft with shrink disc
• Oil compensating tank
• Up to 4,500:1 ratio
• Output torque up to 1,400,000 Nm
